Comprehensive Inventory Management in 3 Simple Steps
Once the desired items are properly tagged and placed in the Undercounter ULT RFID Freezer, pre-authorized users can access the enclosure by placing their badge to the pass reader.
Securely shut the door to the Undercounter ULT RFID Freezer to ensure a scan of the inventory is performed. Whether the user adds or removes an item, the system automatically tracks the transaction in real-time, recording who took the product and when.
This recorded encrypted transaction is then transferred via Jetstream, our cloud-based platform which can be easily integrated into your existing ERP systems. Need an inventory management software of your own to access all that valuable information? That’s why we have Stratosphere, the perfect end-to-end inventory management software solution.
One technology. Many applications
Be it product or place, the Undercounter ULT RFID Freezer has a multitude of uses.
- Reagents
- Bio-samples
- Pharmaceuticals
- Cardiovascular products
- Orthopedic supplies
- Adhesives
- Sample tracking
Model number: TS079
Component
External Dimensions (H x W x D): US: 32.7 in. x 35.4 in. x 25 in.
Internal Dimensions (H x W x D): US: 25.2 in. x 18.9 in. x 13 in.
External Space Required (H x W x D): US: 32.7 in. x 40 in. x 50 in.
- Place 3 in. from back wall
- Allow 21 in. for door clearance
Volume: 3.6 ft3
Weight: 265 lbs
Cooling Method: 2-stage cascade system
Access Control: LF badge
Communication
Ethernet, optional cellular
RAIN RFID Frequency: US: 902 to 928 MHz
Power
Electrical Power: 120 VAC, 60 Hz, 5 A
Power Consumption: 367 W max
Battery Backup: Up to 2 hrs
Temperature
-86 °C to -50 °C
Warranty
Lease: 36 months
Purchase: 36 months
Certifications: RAIN, SGS, FCC, RoHS, IP41 Rated
Disclaimer: If you are outside of the US and EU contact us for your regions’ specifications
- Hospitals
- Research labs
- Tissue storage facilities
- Ambulatory Surgery Centers
- Pharmacies
- Biobanks
- Crime labs
- Stockrooms
- Aerospace
- Consignment inventory
One technology. Many applications
Be it product or place, the Undercounter ULT RFID Freezer has a multitude of uses.
- Reagents
- Bio-samples
- Pharmaceuticals
- Cardiovascular products
- Orthopedic supplies
- Adhesives
- Sample tracking
Model number: TS079
Component
External Dimensions (H x W x D): US: 32.7 in. x 35.4 in. x 25 in.
Internal Dimensions (H x W x D): US: 25.2 in. x 18.9 in. x 13 in.
External Space Required (H x W x D): US: 32.7 in. x 40 in. x 50 in.
- Place 3 in. from back wall
- Allow 21 in. for door clearance
Volume: 3.6 ft3
Weight: 265 lbs
Cooling Method: 2-stage cascade system
Access Control: LF badge
Communication
Ethernet, optional cellular
RAIN RFID Frequency: US: 902 to 928 MHz
Power
Electrical Power: 120 VAC, 60 Hz, 5 A
Power Consumption: 367 W max
Battery Backup: Up to 2 hrs
Temperature
-86 °C to -50 °C
Warranty
Lease: 36 months
Purchase: 36 months
Certifications: RAIN, SGS, FCC, RoHS, IP41 Rated
Disclaimer: If you are outside of the US and EU contact us for your regions’ specifications
- Hospitals
- Research labs
- Tissue storage facilities
- Ambulatory Surgery Centers
- Pharmacies
- Biobanks
- Crime labs
- Stockrooms
- Aerospace
- Consignment inventory
Gallery
Ultra-High Frequency Radio Frequency Identification technology, also known as RAIN RFID, has an extremely high read range compared to both LF and HF RFID tags. This makes RAIN RFID the ideal solution when trying to track multiple products at one time, such as large boxes full of product that is passing through a space, or a cabinet full of inventory. Better understanding the technology enables you to make an informed decision and, should you decide to partner with us, the support doesn’t end here. From discovery to roll-out, we will be there every step of the way to ensure a successful implementation of this cutting-edge technology.
The Undercounter ULT RFID Freezer would not be able to communicate essential inventory information to end users without a software platform, which is why we developed Jetstream with security and scalability in mind. Jetstream is the simplest cloud-based platform for managing inventory so that staying connected to RFID tagged items from anywhere at anytime is possible.
