Comprehensive Inventory Management in 3 Simple Steps
Once the desired items are properly tagged and placed in the Large ULT RFID Freezer, pre-authorized users can access the enclosure by placing their badge to the pass reader.
Once the door to the Large ULT RFID Freezer is securely shut a scan of the inventory is performed. Whether the user adds or removes an item, the system automatically tracks the transaction in real-time.
This recorded encrypted transaction is then transferred via Jetstream, our cloud-based platform which can be easily integrated into your existing ERP systems and inventory management workflows. Need an inventory management software, but don’t want to develop your own? Stratosphere is the solution for you.
One technology. Many applications.
Be it product or place, the Large ULT RFID Freezer has a multitude of uses.
- Reagents
- Bio-samples
- Pharmaceuticals
- Vaccines
- Cardiovascular products
- Orthopedic supplies
- Adhesives
Model number: TS057
Component
External Dimensions: US: 78”H x 38”W x 37”D | EU: 1981 H x 965 W x 940 D (mm)
Internal Dimensions: US: 52”H x 23”W x 19”D | EU: 1321 H x 584 W x 483 (mm)
External Space Required: US: 83”H x 52”W x 81”D | EU: 2108 H x 1321 W x 2057 D (mm)
- Place 6” (152 mm) from back wall
- Allow 34” (864 mm) for door clearance
Volume: 13 ft3 (368 L)
Weight: 725 lbs (329 kg)
Cooling Method: 2-stage cascade system
Access Control: LF badge
Communications
Ethernet, optional cellular or WiFi
RAIN RFID Frequency: US: 902 to 928 MHz | EU: 864 to 868 MHz
Electrical Power: US: 120 VAC, 60 Hz, 16 A
Power
Power Consumption: 1.9 KW max
Battery Backup: Up to 2 hrs
Temperature
-85°C to -50°C
Certifications: RAIN, SGS, FCC, RoHS, IP41 Rated
- Hospitals
- Research labs
- Tissue storage facilities
- Pharmacies
- Biobanks
- Crime labs
- Stockrooms
- Aerospace
- Consignment inventory
One technology. Many applications.
Be it product or place, the Large ULT RFID Freezer has a multitude of uses.
- Reagents
- Bio-samples
- Pharmaceuticals
- Vaccines
- Cardiovascular products
- Orthopedic supplies
- Adhesives
Model number: TS057
Component
External Dimensions: US: 78”H x 38”W x 37”D | EU: 1981 H x 965 W x 940 D (mm)
Internal Dimensions: US: 52”H x 23”W x 19”D | EU: 1321 H x 584 W x 483 (mm)
External Space Required: US: 83”H x 52”W x 81”D | EU: 2108 H x 1321 W x 2057 D (mm)
- Place 6” (152 mm) from back wall
- Allow 34” (864 mm) for door clearance
Volume: 13 ft3 (368 L)
Weight: 725 lbs (329 kg)
Cooling Method: 2-stage cascade system
Access Control: LF badge
Communications
Ethernet, optional cellular or WiFi
RAIN RFID Frequency: US: 902 to 928 MHz | EU: 864 to 868 MHz
Electrical Power: US: 120 VAC, 60 Hz, 16 A
Power
Power Consumption: 1.9 KW max
Battery Backup: Up to 2 hrs
Temperature
-85°C to -50°C
Certifications: RAIN, SGS, FCC, RoHS, IP41 Rated
- Hospitals
- Research labs
- Tissue storage facilities
- Pharmacies
- Biobanks
- Crime labs
- Stockrooms
- Aerospace
- Consignment inventory
Gallery
Ultra-High Frequency Radio Frequency Identification technology, also known as RAIN RFID, has an extremely high read range compared to both LF and HF RFID tags. This makes RAIN RFID the ideal solution when trying to track multiple products at one time, such as large boxes full of product that is passing through a space, or a cabinet full of inventory. Better understanding the technology enables you to make an informed decision and, should you decide to partner with us, the support doesn’t end here. From discovery to roll-out, we will be there every step of the way to ensure a successful implementation of this cutting-edge technology.
Without a software platform, the Large ULT RFID Freezer would not be able to communicate essential inventory information to end users. But don’t worry, we’ve got you covered. Jetstream, the most flexible cloud-based platform for managing inventory allows for security and scalability so that staying connected to high-value inventory from anywhere at anytime is not only possible but easy. So you can know now.
Reston Hospital, located in Reston, Virginia, found that it’s process of manually tracking tissue grafts resulted in roughly $200,000 in write-offs and made establishing regulation compliance difficult. With the integration of our RFID-enabled enclosures with UDITracker Software from Champion, Reston Hospital reduced product loss, allowed for regulatory compliance, which in turn improved patient safety and decreased liability.
